WD10JMVW-11S5XS1 2060-771823-000 HDD Repair and Data Recovery Steps

,

Here is the video on how to recover lost data from WD10JMVW 11S5XS1 undetected hard drives without data access.

Patient HDD ID details:

Model number: WD10JMVW 11S5XS1
Family: Firebird
PCB: 2060-771823-000
Head number: 4

If users enter DFL-WD hdd firmware repair program, the HDD ID couldn’t be detected properly and the firmware modules are not accessed too.

To recover lost data from this kind of cases, users need to short connect TV9 and TV10 and enter program, backup ROM, disable 02, firmware restart, re-enter the program.

After above steps, the firmware modules were already available.

Next the engineer went to click the common repair-Slow fix and unlock smartware.

Next the engineer tested all the firmware modules and found out which modules were corrupted. The module 32 was corrupted, the engineer found one donor 32, wrote to hdd and cleared the module 32.

Next the engineer enabled module 02, firmware restart.

Next the patient HDD was perfectly fixed and the data area was accessed too.

Next the engineer opened DFL-DDP data recovery program and all lost data was perfectly recovered.

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

/0 Comments/by

WD HDD SED Lock Firmware Lock Data Lock MCU Lock

, ,

For data recovery engineers worldwide, Western Digital hdd recovery is one type of typical data recovery case. Among all WD cases, users can meet SED patient drives, firmware locked drives, data locked drives and MCU locked drives. Read more

/by

WD 8X00XX HDD SED Data Encryption Data Recovery Steps

,

The WD 8X00XX HDD SED Data Encryption hard drives we are talking about in this article are the Western Digital portable hard drives with USB PCB numbers of 2060-800041, 800067, 800069, 810003, 810012, 810035. Besides 800041, the other USB HDDs above have both MCU and SED lock, 800041 USB HDD has SED lock. Read more

/by

WD Undetected WD10JMVW-11AJGS4 Portable Hard Drive Data Recovery Steps and Tools

,

To recover lost data from Western Digital undetected portable hard drives is very common data recovery case in all data recovery labs.

This kind of patient hdds are usually corrupted due to the firmware failure or head failure, common pc users or IT engineers without professional data recovery equipment are not expected  to fix the failure and get lost data back. Read more

/by

DFL Unique Data Recovery Tips for WD 2060-810011 CARMEL HDDs

,

Recently Dolphin users in many countries reported one special data recovery case on the new Western Digital WD20EZAZ-00L9GB0 hard drives, the HDD family is CARMEL and the PCB number is WD 2060-810011.

These WD20EZAZ-00L9GB0 hard drives have MCU lock and users cannot access to the ROM and firmware area. Read more

/by

WD40NMZW-11GX6S1 Forgot Smartware Password Data Recovery

,

This is one of success cases done by DFL engineer today for an Ecuador user. The drive has smartware lock.

HDD ID
Patient drive: WD40NMZW-11GX6S1 PCB: 810041
Firmware: 01.01A01 Capacity: 4TB
Read more

/by

WD40EZRZ-00WN9B0 Undetected HDD Recovery by DFL Data Recovery Tools

,

This is one Western Digital-WD40EZRZ-00WN9B0 hard drive firmware repair and data recovery case study for one DFL user in Indonesia. Read more

/by

WD10TMVW-11ZSMS4 Data Recovery Steps by DFL-WD HDD Repair Tool

,

This is one of success data recovery cases done by DFL engineer today for an Australian user. The patient drive cannot read PCB information and module list.

HDD ID

Patient drive: WD10TMVW-11ZSMS4
PCB:2060-771692-005 REV A
Family: HELIOS Capacity: 1TB

Read more

/by

WD40NMZW-11GX6S1 Spyglass New Slow Issue

,

Today when our Dolphin data recovery engineer was working on one Western Digital Spyglass 4TB hard drive, one new slow issue was found on the patient hard drive.

Read more

/by

Warning to Recover Lost Data from WD HDD Palmer Charger Families

,

WD HDD palmer, charger families are pointing to the new western digital hard drives of PCB 800066, 800069, 800067, 800065, etc. To recover lost data from these new hdds, it is more difficult than to recover lost data from traditional western digital hdds.

Read more
