Seagate HDD ST1000LM035 MCMT table is corrupted

“MCMT table is corrupted” is one very common firmware error output in the COM terminal. The following patient HDD is one firmware corrupted case from one Italian DFL user.

The following are the detailed error messages:

Tech Unlock Handshake: 0xC66A98E3
Reply:
QB
Rst 0x80M
Srv DETCR init 0x0000

(P) SATA Reset

RAW OFF

PASS
(DOS Table) Worst Count: 00000000 At SU: FFFFFFFF NT: 00000000 OT: 00000000

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

MCMT table is corrupted

Intel 6G->3G

Send Status: COMRESET seen

CSpd= 3Gbps
ResetAbortDst
ResetAbortDST
ResetAbortDST

(H) SATA Reset

SSPSaveSettings

Send Status: COMRESET seen

CSpd= 3Gbps

DSC

MCMT table is corrupted

To fix above case, the user made a backup of the original rom, generated unlock rom, wrote unlock rom, power off and on, send unlock key, backup the important SYS files, cleared glist and regenerated translator. During this firmware repair process, users must pay attention to the NGlist entries before and after the translator regneration. This will help to fix the HDD partial sector access issue easily.
