Samsung LED Error 110B and LED 1703
***** VCM is stucked : status 1
SoUL!
Abnormal end
PK_3 C: 0 H:3
Unlatch Fail
EPOKSoftware unloading!
PK_4 C: 0 H:0
Software unloading!
PK_4 C: 0 H:0
LED 110B
LED 110B
LED 110B
LED 110B
LED 110B
eng>LED 110B
RT
ﾆuSﾋQq3QQuￕQQwﾳￋPﾢTￂﾆuSﾋQq3QQuￕQQwﾳￋﾢￂ PￊￕﾀA] ￍU
S_0Shock Sensor Circuit Enabled
SO_1
Shock Sensor Circuit Enabled
IS Fail
CSRTY=1 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=2 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=3 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=4 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=5 RPM=0
SP Startup Fail
SO_2 C=5,A=0,S=1,RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=1 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=2 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=3 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=4 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=5 RPM=0
SP Startup Fail
SO_2 C=5,A=0,S=2,RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=1 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=2 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=3 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=4 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=5 RPM=0
SP Startup Fail
SO_2 C=5,A=0,S=3,RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=1 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=2 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=3 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=4 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=5 RPM=0
SP Startup Fail
SO_2 C=5,A=0,S=4,RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=1 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=2 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=3 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=4 RPM=0
Shock Sensor Circuit Enabled
IS Fail
CSRTY=5 RPM=0
SP Startup Fail
SO_2 C=5,A=0,S=5,RPM=0
SO_3 R Sp Err
SpinUp Fail
EPOK
SoUL!
PK_4 C: 0 H:0
LED 1703
LED 1703
LED 1703
LED 1703
Samsung LED error Causes:
1, PCB damage, the most common is that the driver IC is damaged;
2, Head stuck on platter-Common;
3, Motor contacts between motor and PCB are bad/ with oxidation-Common;
4, Motor coil short failure, need to remove platters to donor hdd;
5, Motor gets jammed and need to require platter swap-Common.
Any more question is welcome to [email protected] or add dolphin skype ID: dolphin.data.lab
