DFL-URE and HDD ROM Chip Pin Reader Help With Easier WD SMR HDD Firmware Unlock

More and more WD SMR HDD data recovery cases are coming to data recovery labs worldwide. DFL-URE data recovery express and HDD ROM Chip Pin Reader Help With Easier WD SMR HDD Firmware Unlock and data recovery.

DFL-URE or DFL-UREP contains the following modules:

DFL-WD hdd repair
DFL-Samsung hdd repair
DFL-DDP data recovery

How to Unlock WD SMR HDD Firmware Area without Firmware Unlock PCB

Step 1: Remove original PCB;

Step 2: Read original ROM by HDD ROM Chip Pin reader, no need to solder rom chip off;

Step 3: Enter DFL-WD HDD Repair Tool, go to ROM Operations>Unlock ROM;

Step 4: Select original rom and the DFL WD program will automatically generate one unlock ROM;

Step 5: Write Unlock ROM by HDD ROM Chip Pin Reader, no need to solder rom chip off;

Step 6: Install original PCB to original HDD, users can connect original HDD to DFL-URE or DFL-UREP to backup module 190, repair 190 and then use auto loading tech. to image hdd or extract lost data directly.

Video Demo on How to Unlock WD SMR HDD Without Firmware Unlock PCB:

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab
