Example models of WD PCB 800065 800067 810003 SMR HDDs:
2060-800067-001：
WD20SMZW-11JW8S0
WD20SMZW-11JW8S1
WD20SMZW-11YFCS0
WD20SMZW-34JW8S0
WD20SMZW-34JW8S1
WD20SMZW-59JW8S1
WD20SMZW-59YFCS0
WD20SMZW-59YFCS1
WD20SMRW-59YNDS0
WD20SDZW-11Z3CS0
WD20SDRW-11VUUS0
WD20SDRW-34VUUS0
WD15SMZW-11YFCS0
WD15SMRW-11YNDS0
2060-800065-002：
WD20SPZX-08UA7T0
WD20SPZX-11CRAT0
WD20SPZX-22CRAT0
WD20SPZX-21UA7T0
WD20SPZX-75UA7T1
2060-810003-001：
WD20SDZM-59TM5S1
WD20SMZM-59H3FS1
HDD Family: Charger
Please note WD PCB 800065 800067 810003 HDDs are SMR drives with module 190 and users can select the following tools which are helpful for firmware repair and data recovery.
WD HDD Compatible SATA PCB for USB PCB 800067 and 810003: 800065
Find the Compatible Unlock SATA PCB 800065 here
WD PCB 800065 800067 810003 HDD Firmware Repair Tool: DFL WD HDD Firmware Repair Tool
Users can repair WD HDD firmware module damage, reset smart, remove password, edit HDD ID, etc.
WD PCB 800065 800067 810003 HDD Data Recovery Tool: DFL DDP Data Recovery Equipment
Users can repair module 190, auto load T2data, image WD HDDs with weak heads, bad sectors, common firmware failures, can extract lost partitions, folders, files, etc;
WD PCB 800065 800067 810003 SMR HDD Head Replacement Tool
WD 800067 USB-SATA Adapter Smart
WD 810003 USB-SATA Adapter Smart
G3 WD SMR HDD 800067 USB-SATA Data Recovery Adapter Pro.
G3 WD SMR HDD 810003 USB-SATA Data Recovery Adapter Pro.
Chip-on HDD Flash Programmer Smart/HDD ROM Chip Pin Reader
Users don’t need to solder ROM chips off and read rom chip directly, super easy for WD SMR HDD ROM read and write
Example models of WD PCB 800066 800069 800086 SMR HDDs:
WD10SPZX-24Z10T1 2060-800066-006 P1
WD10SPZX-22Z10T0 2060-800066-004
WD10SPZX-24Z10T0 2060-800066-004
WD10SPZX-60Z10T0 2060-800066-006
WD10SMZW-11Y0TS0 2060-800069-001
WD10SMZW-59Y0TS0 2060-800069-001 REV P1
HTS541010BE610 2060-800066-004 Rev P1
WD5000LMZW-11Y0TS0 2060-800069-001
WD10SMZW-34Y0TS0 800069-001
WD10SDZW-11UMGS0 2060-800069-001
WD10SDZW-59UMGS0 2060-800069-001
WD10SDRW-11A0XS0 2060-800069-001
WD10SDRW-11A0XS1 2060-800069-003
WD10SDRW-34A0XS0 2060-800069-003 REV P1
WD10SMZM-59WKCS0 2060-800086-000 Type C
HDD Family: Palmer
Please note WD PCB 800066 800069 800086 HDDs are SMR drives with module 190 and users can select the following tools which are helpful for firmware repair and data recovery.
WD HDD Compatible SATA PCB for USB PCB 800069 and 800086: 800066
Find the Compatible Unlock SATA PCB 800066 here
WD PCB 800066 800069 800086 HDD Firmware Repair Tool: DFL WD HDD Firmware Repair Tool
Users can repair WD HDD firmware module damage, reset smart, remove password, edit HDD ID, etc.
WD PCB 800066 800069 800086 HDD Data Recovery Tool: DFL DDP Data Recovery Equipment
Users can repair module 190, auto load T2data, image WD HDDs with weak heads, bad sectors, common firmware failures, can extract lost partitions, folders, files, etc;
WD PCB 800066 800069 800086 SMR HDD Head Replacement Tool
WD 800069 USB-SATA Adapter Smart
G3 WD SMR HDD 800086 USB-SATA Data Recovery Adapter Pro.
Chip-on HDD Flash Programmer Smart/HDD ROM Chip Pin Reader
Users don’t need to solder ROM chips off and read rom chip directly, super easy for WD SMR HDD ROM read and write
Example models of WD PCB 800041 810012 800022 HDDs:
2060-800041-003
WD50NDZW-11MR8S1
WD40NMZW-59GX6S1
WD40NMZW-11GX6S1
WD40NDZW-11MR8S1
WD40NDZW-11MR8S0
WD40NMZW-34GX6S1
WD30NDZW-11MR8S1
WD30NMZW-11GX6S1
WD30NMZW-59GX6S1
WD30NMZW-11A8NS1
WD30NMZW-11LG6S1
WD30NMZW-11LG6S0
2060-810012-000
WD40NDZM-59PW8S1
WD40NMZM-59Y94S1
2060-800022-000
WD30NPRZ-00YRMT0
WD30NPRZ-11YRMT0
2060-800022-002
WD40NPZZ-00PDPT0
WD30NPZZ-00PDPT0
HDD Family: Spyglass/Spyglass 2
Please note the old WD PCB 800041 800022 Spyglass HDDs don’t have module 190 and they are not SMR drive, users can try to short connect TV9 and TV10 to access the firmware area if the patient drives are undetected or busy; For Spyglass 2 drives, they are SMR drives with module 190 and users can select the following tools which are helpful for firmware repair and data recovery.
Compatible SATA PCB for USB PCB 800041 and 810012: 800022
Find the compatible SATA PCB 800022 here
WD PCB 800041 810012 800022 HDD Firmware Repair Tool: DFL WD HDD Firmware Repair Tool
Users can repair WD HDD firmware module damage, reset smart, remove password, edit HDD ID, etc.
WD PCB 800041 810012 800022 HDD Data Recovery Tool: DFL DDP Data Recovery Equipment
Users can repair module 190, auto load T2data, image WD HDDs with weak heads, bad sectors, common firmware failures, can extract lost partitions, folders, files, etc;
WD PCB 800041 810012 800022 HDD Head Replacement Tool
WD 800041 USB-SATA Adapter Smart
G3 WD SMR HDD 800041 USB-SATA Data Recovery Adapter Pro.
WD 810012 USB-SATA Adapter Smart
G3 WD SMR HDD 810012 USB-SATA Data Recovery Adapter Pro.
Chip-on HDD Flash Programmer Smart/HDD ROM Chip Pin Reader
Users don’t need to solder ROM chips off and read rom chip directly, super easy for WD SMR HDD ROM read and write
WD HDD Compatible SATA PCB for USB PCB 800038: 800025
Find the compatible SATA PCB 800025 here
WD PCB 800038 800025 HDD Firmware Repair Tool: DFL WD HDD Firmware Repair Tool
Users can repair WD HDD firmware module damage, reset smart, remove password, edit HDD ID, etc.
WD PCB 800038 800025 HDD Data Recovery Tool: DFL DDP Data Recovery Equipment
Users can image WD HDDs with weak heads, bad sectors, common firmware failures, can extract lost partitions, folders, files, etc;
WD PCB 800038 800025 HDD Head Replacement Tool
Example models of WD PCB 800038 800025 HDDs:
WD2500LMCW-11D9GS3 800038
WD5000LMCW-11T31S1 800038
WD5000LPCX-22VHAT0 800025
WD5000LUCX-28LYRY0 800025
HDD Family: Hubble LT / HubLT2
Please note: WD PCB 800038 800025 HDDs don’t have module 190 and it is not SMR drive, users can try to short connect TV9 and TV10 to access the firmware area.
Chip-on HDD Flash Programmer Smart/HDD ROM Chip Pin Reader
Users don’t need to solder ROM chips off and read rom chip directly, super easy for WD SMR HDD ROM read and write
Many new users wish to learn more about the features of Dolphin CCTV DVR data recovery software. Users can learn this actually by using the DVR recovery trial software.
Here is a proven list of Dolphin DVR features:
01: Dolphin DVR offers Fast Scan, Deep Scan and Raw Scan. Deep scan is to recover lost/deleted CCTV DVR videos, recover format/ dvr device initialized videos; Raw scan is mainly to list the videos for unknown CCTV DVR brands, Raw scan is mainly for test if the videos can be recovered or not from the unknown DVR brands;
02: Dolphin DVR has all-in-one video recovery and repair solutions, it contains not only CCTV DVR NVR HVR data recovery software, it contains also Digital Camera data recovery software, video recorder data recovery software and video repair software;
03: Dolphin DVR supports over 117 international CCTV DVR brands;
04: Support E01, DD Raw, IMG and other types of image files;
05: Recover lost videos from unknown digital cameras;
06: Recover lost videos from unknown video recorders;
07: Support digital forensic data recovery from CCTV DVR with many checksum options:
Real-time checksum options to select:
CRC16
CRC16-CCITT
CRC32
FCS16
FCS32
GHASH32-3
GHASH32-5
GOSTHASH
HAVAL-5-256
MD2
MD4
MD5
SHA1
SHA256
SHA384
SHA512
TIGER
08：Read-only/enable write-blocking as default setting;
09：H.263, H.264 and H.265 video codec support are supported;
10, Partition starting address auto detection is added, this one is very powerful for DVR drives suffering device initialization or format;
11, For any unsupported CCTV, DVR, digital cameras, video recorders, Dolphin engineers can add to support list in a very short time, all users need to do is to provide Dolphin team with one small image file of about 10G around;
etc…
Any question is welcome to [email protected] or add Dolphin Skype ID: dolphin.data.lab
Dolphin Data Lab offers the most cost-effective hard drive head replacement tools to data recovery engineers worldwide for successful physical hdd data recovery.
In many patient drives, the actual platter and head number are different from the designed physical platter and head number. Some of the heads can be cut physically and are not used at all. For example, the patient HDD was designed to have 4 platters and 8 heads but actually the patient HDD has only 3 platters and 6 heads.
The following is one example HDD-MQ03ABB200M:
Users can check the parking ramp carefully and can find the parking ramp has 4 separators(4 platters) and therefore users need to select one head comb with 4 separators.
Watch the video demo here for this patient HDD
Any question is welcome to [email protected] or add Dolphin SKype ID: dolphin.data.lab
